330

330

The Cat® 330 excavator has the speed, efficiency, and power for your heavy-duty applications requiring maximum productivity. You get built-in Cat GRADE with 2D, Grade Assist, and Payload as standard equipment right from the factory – boosting your operational efficiency by up to 45 percent. Combine these features with a new cab, longer maintenance intervals, and increased fuel efficiency, and you have a low-cost-per-unit-of-production excavator built for your heavy-duty applications.

Not all features are available in all regions. Consult your Cat dealer for specific configurations available in your region.

Net Power - ISO 9249 193.8 kW
Operating Weight 31400 kg
Maximum Digging Depth 7250 mm

Technicial Specifications

Engine
Net Power - ISO 9249 193.8 kW
Engine Model Cat C7.1
Engine Power - ISO 14396 195 kW
Bore 105 mm
Stroke 135 mm
Displacement 7.01 l
Weights
Operating Weight 31400 kg
Working Ranges & Forces
Maximum Digging Depth 7250 mm
Boom HD Reach 6.15m (20'2")
Stick HD Reach 3.2 m (10'6")
Bucket HD 1.80 m³ (2.35 yd³)
Maximum Reach at Ground Level 10690 mm
Maximum Cutting Height 10000 mm
Maximum Loading Height 6950 mm
Minimum Loading Height 2290 mm
Maximum Depth Cut for 2440 mm (8 ft) Level Bottom 7090 mm
Maximum Vertical Wall Digging Depth 5790 mm
Bucket Digging Force - ISO 179 kN
Stick Digging Force - ISO 126 kN
Hydraulic System
Main System - Maximum Flow 560 l/min (148 gal/min)
Maximum Pressure - Equipment 35000 MPa
Maximum Pressure - Equipment - Lift Mode 38000 kPa
Maximum Pressure - Travel 35000 kPa
Maximum Pressure - Swing 29800 kPa
Swing Mechanism
Swing Speed 11.5 r/min
Maximum Swing Torque 110 kN·m
Service Refill Capacities
Fuel Tank Capacity 474 l
Cooling System 25 l
Engine Oil 25 l
Swing Drive - Each 2.6 l
Final Drive - Each 5.5 l
Hydraulic System - Including Tank 310 l
Hydraulic Tank 147 l
DEF Tank 41 l
Dimensions
Boom HD Reach 6.15m (20'2")
Stick HD Reach 3.2 m (10'6")
Bucket HD 1.80 m³ (2.35 yd³)
Shipping Height - Top of Cab 3060 mm
Handrail Height 3060 mm
Shipping Length 10420 mm
Tail Swing Radius 3130 mm
Counterweight Clearance 1120 mm
Ground Clearance 490 mm
Track Length 4860 mm
Length to Center of Rollers 3990 mm
Track Gauge 2590 mm
Transport Width 3390 mm

Advantages and Features

POWERFUL EFFICIENCY

  • Increase fuel efficiency up to 15 percent over the 330D2 excavator.
  • Lift more with up to 15 percent improved lift capacity and increased bucket size over the 330D2 excavator.
  • Make working on slopes easier with five percent improved swing torque over the 330D2 excavator.
  • Increase operating efficiency up to 45 percent with standard Cat technologies that lower operator fatigue and your operating costs, including fuel consumption and daily maintenance.
  • The C7.1 engine can run on biodiesel up to B20 and meets China Nonroad Stage III, UNECE R96 Stage IIIA, and Brazil MAR-1 emission standards, equivalent to U.S. EPA Tier 3/EU Stage IIIA.
  • The advanced hydraulic system provides the optimum balance of power and efficiency while giving you the control you need for precise digging requirements
  • Match the excavator to the job with power modes; let Smart mode automatically match engine and hydraulic power to digging conditions.
  • Advansys™ bucket tips increase penetration and improve cycle times. Tip changes can be done quickly with a simple lug wrench instead of a hammer or special tool, improving safety and uptime.
  • Auxiliary hydraulic options give you the versatility to use a wide range of Cat attachments.
  • Don’t let the temperature stop you from working. The excavator has a standard high-ambient temperature capability of 52°C (125°F) with de-rate and cold start capability of –18°C (0°F). An optional –32°C (-25°F) cold start package is available.

PRODUCTIVITY WITH TECHNOLOGY

  • Boost productivity up to 45 percent versus traditional grading with standard Cat GRADE with 2D system - includes indicate-only and laser capability.
  • Dig with guidance to depth, slope, and horizontal distance to grade. You can set up to four different target depth and slope offsets to help save time and money. When the job calls for a different offset, quickly switch through the monitor and get to work.
  • The 2D system is upgradable to Cat GRADE with Advanced 2D or Cat GRADE with 3D.
  • Standard Grade Assist -
  1. Stay on grade – simply and effortlessly – with single-lever digging.
  2. Set your desired bucket angle and let Bucket Assist automatically maintain the angle in sloping, leveling, fine grading, and trenching applications for easy, accurate, and fast jobs.
  3. Keep the tracks on the ground in lifting and hard digging with Boom Assist.
  4. Automatically stop excavator swing at operator-defined set points in truck loading and trenching applications with Swing Assist, which will help you use less effort and consume less fuel.
  • Standard Cat PAYLOAD onboard weighing system -
  1. Achieve precise load targets and increase loading efficiency with on-the-go weighing and real-time estimates of your payload without swinging.
  2. Take payload data with you. The monitor’s USB port lets you download your results from one shift all the way up to 30 days of work so can manage your progress without needing an internet connection or VisionLink subscription.
  3. Track your daily productivity such as truck target weights and load/cycle counts.
  4. Calibration can be performed in a matter of minutes.
  5. Combine Payload with VisionLink® and remotely manage your production targets.
  • Upgrade to optional Cat GRADE with Advanced 2D -
  1. Create and edit grade designs with ease on a second high-resolution 254 mm (10 in) touchscreen monitor.
  • Upgrade to optional Cat GRADE with 3D -
  1. Create and edit designs with ease and see the front linkage’s full range of motion on a second high-resolution 254 mm (10 in) touchscreen monitor.
  2. Use the excavator’s onboard cell technology to quickly connect to 3D services like TCC or VRS.
  3. Know the excavator ’s exact position relative to GPS and GLONASS systems.
  4. Already invested in another brand’s 3D system? No problem. Standard Cat technology like GRADE with 2D can readily integrate with that system to give you the precise results you need.
  5. The machine automatically compensates for excavator pitch and roll caused by sloping ground conditions.
  6. Antennas have theft-prevention bolts; a special tool makes them easy for the owner to remove at the end of a shift.
  • The standard 2D E-fence feature integrated right out of the factory prevents the excavator from moving outside operator-defined set points.
  • Standard Product Link™ collects data automatically and accurately from your assets – any type and any brand. Information such as location, hours, fuel usage, productivity, idle time, maintenance alerts, diagnostic codes, and machine health can be viewed online through web and mobile applications.
  • All Cat Grade systems are compatible with radios and base stations from Trimble, Topcon, and Leica. Already invested in a grade infrastructure? You can install grade systems from Trimble, Topcon, and Leica onto the machine.

BETTER COMFORT AND CONTROL

  • Choose between Deluxe and Premium cabs – both with automatic climate control.
  • The Deluxe seat is heated and air adjustable. The Premium seat is heated and cooled and adjusts automatically.
  • Get in and out of the cab easier using the tip-up left console.
  • Advanced viscous mounts reduce cab vibration up to 50 percent over previous excavator models.
  • Control the excavator comfortably with easy-to-reach controls all located in front of you.
  • Stow your gear with plenty of in-cab storage beneath and behind the seat, overhead, and in the consoles. A cup holder, document holder, bottle holder, and coat hook are also provided.
  • Use the standard radio’s USB ports and Bluetooth® technology to connect personal devices and make hands-free calls.

SIMPLE TO OPERATE

  • Start the engine with a push button; use a Bluetooth key fob, or the unique Operator ID function.
  • Program your power mode and joystick preferences using Operator ID; the excavator will remember what you set each time you go to work.
  • Navigate quickly on the standard high-resolution 203 mm (8 in) touchscreen monitor, or with the optional 254 mm (10 in) touchscreen monitor, or with the aid of the jog dial control.
  • Protect your hammer from overworking. Auto hammer stop warns you after 15 seconds of continuous firing and then automatically shuts it off after 30 seconds -- all to prevent wear and tear on the attachment and excavator.
  • A second 254 mm (10 in) monitor is available for the advanced grade control.
  • Not sure how a function works or how to maintain the excavator? Always have the operator’s manual at your fingertips in the touchscreen monitor.
  • Find the tool you need – even if it’s hidden beneath overgrowth or debris. The excavator’s onboard Bluetooth reader can search for any work tool equipped with Cat asset tracking devices up to a range of 60 meters (200 feet).
  • The Cat PL161 Attachment Locator is a Bluetooth device that makes finding your attachments and other gear quick and easy. The excavator's onboard Bluetooth reader or Cat App on your phone will locate the device automatically.
  • Save more time and energy with the available work tool recognition feature. A simple shake of the attached tool confirms its identity; it also ensures all the attachment settings are correct so you can get to work quickly and efficiently.
  • Auto Dig Boost increases power by up to 8% for better bucket penetration, shorter cycle times, and greater payloads.
  • Make moving the excavator much easier with Cat Stick Steer. Simply push a button and use one hand to travel and turn instead of both hands or feet on levers or pedals.
  • Need more lift during your shift? Turn on Auto Heavy Lift and get 8% more power exactly when you need it for as long as you need it.

LOWER MAINTENANCE COSTS

  • Expect up to 25 percent less maintenance cost than the 330D2 (savings calculated over 12,000 machine hours).
  • Do all daily maintenance at ground level.
  • Check engine oil level quickly and safely with the new ground-level engine oil dipstick; fill and check engine oil on top of the machine with a conveniently located second dipstick.
  • Track your excavator’s filter life and maintenance intervals via the in-cab monitor.
  • Do no required maintenance on the Cat Clean Emissions Module.
  • Using Cat genuine oil and filters and doing your typical S∙O∙S monitoring will double the current service interval to 1,000 hours, giving you greater uptime to do more work.
  • Expect the new air intake filter with pre-cleaner to last up to 1,000 hours – a 100 percent increase over the previous filter.
  • The new hydraulic oil filter provides improved filtration performance, anti-drain valves to keep oil clean when the filter is replaced, and longer life with a 3,000-hour replacement interval – 50 percent longer than previous filter designs.
  • High-efficiency cooling fans run only when needed; you can program intervals so they automatically reverse to keep cores clean without interrupting your work
  • S·O·S ports are on ground level, simplifying maintenance and allowing for quick, easy extraction of fluid samples for analysis.

BUILT-IN SAFETY FEATURES

  • Lift Assist helps you avoid tipping. With visual and auditory alerts, you’ll know if your load is within the excavator’s safe working range limits.
  • Access 100 percent of daily maintenance points from ground level – no need for you to climb on top of the excavator.
  • The standard ROPS cab meets ISO 12117-2:2008 requirements.
  • Enjoy great visibility into the trench, in each swing direction, and behind you with the help of smaller cab pillars, larger windows, and a flat engine hood design.
  • The standard hydraulic lockout lever isolates all hydraulic and travel functions in the lowered position.
  • Ground-level shut-off switch stops all fuel to the engine when activated and shuts down the machine.
  • A rearview camera and a right-side-view camera are standard. Upgrade to 360° visibility and you’ll easily visualize objects and personnel around the excavator in a single view.
  • New right service platform design provides easy, safe, and quick access to upper service platform; the service platform steps use anti-skid punch plate to prevent slipping.

Standard Equipment

  • NOTE
    • Standard and optional equipment may vary. Consult your Cat dealer for details.
  • CAB
    • ROPS, standard sound suppression
    • Mechanically-adjustable seat
    • High-resolution 203 mm (8 in) LCD touchscreen monitor
  • CAT CONNECT TECHNOLOGY
    • Cat Product Link
    • Cat GRADE with 2D
    • Cat GRADE with Assist
    • Cat PAYLOAD
    • 2D E-Fence
    • Lift Assist
    • Auto Dig Boost
  • ENGINE
    • Three selectable power modes
    • One-touch low idle with auto engine speed control
    • Auto engine idle shutdown
    • 52°C (125°F) high-ambient cooling capacity with de-rate
    • Double element air filter with integrated precleaner
    • Reversing electric cooling fans
    • Biodiesel capability up to B20
  • HYDRAULIC SYSTEM
    • Boom and stick regeneration circuits
    • Auto hydraulic warm up
    • Auto two-speed travel
    • Boom and stick drift reduction valve
  • UNDERCARRIAGE AND STRUCTURES
    • Tie-down points on base frame
    • 6700 kg (14,770 lb) counterweight
  • ELECTRICAL SYSTEM
    • Two 1,000 CCA maintenance free batteries
    • Programmable time-delay LED working lights
    • LED chassis light, left-hand/right-hand boom lights, cab lights
  • SERVICE AND MAINTENANCE
    • Sampling ports for Scheduled Oil Sampling (S·O·S)
    • Ground-level and platform-level engine oil dipsticks
  • SAFETY AND SECURITY
    • Rearview camera and right-hand mirror
    • Right-side-view camera (Turkey only)
    • Ground-level engine shutoff switch
    • Right-hand handrail and hand hold
    • Signaling/warning horn

Optional Equipment

  • NOTE
    • Standard and optional equipment may vary. Consult your Cat dealer for details.
  • CAB
    • Air-adjustable seat with heat (Deluxe only)
    • Cat Stick Steer
  • CAT CONNECT TECHNOLOGY
    • Cat GRADE with Advanced 2D
    • Cat GRADE with 3D
  • ENGINE
    • -32°C (-25°F) cold start capability
  • HYDRAULIC SYSTEM
    • Boom and stick lowering check valves
    • Hammer return filter circuit
    • Tool Control (two pump, one/two way high-pressure flow)
    • Basic Tool Control (one pump, one way high-pressure flow)
    • Auto Heavy Lift
  • BOOM AND STICK
    • 6.15 m (20'2") HD reach boom, 3.2 m (10'6") HD reach stick
    • 6.15 m (20'2") HD reach boom, 2.65 m (8'8") HD reach stick
    • 5.55 m (18'2") mass boom, 2.5 m (8'2") mass stick
  • UNDERCARRIAGE AND STRUCTURES
    • 800 mm (31") triple grouser shoes
  • SERVICE AND MAINTENANCE
    • Electric refueling pump with auto shut off
  • ELECTRICAL SYSTEM
    • Premium surround lighting package
  • SAFETY AND SECURITY
    • 360° visibility
    • Right-side-view camera
    • 360° visibility
    • Right-side-view camera
